PlanOn PRINTSTIK Review

by Sarah Meyer

Ever wonder what the world's smallest printer would look like and how it would perform? Well, we have the answer to your musings with our review of PlanOn's new Printstik mobile printer.

Ok, so the claim that the Printstik is the "world' smallest" is PlanOn's, not ours, but it does weigh in at less than 2 lbs. We also tested its performance ... care to know more?

(view large image)

PRINTSTIK (PS910) Specifications:

• Resolution: Approx. 200x100 dpi, 200x200 dpi, 200x400 dpi
• Direct thermal printing
• Paper: 8.5" wide, 20 pages per roll
• Power supply: AC - 100-240 VAC, 50 or 60 Hz with adapter; DC - 12/24 VDC from Auto lighter socket
• USB system requirements: Windows XP, Windows Vista, or Blackberry
• Bluetooth system requirements: Stereo Bluetooth v2.0 (A2DP)
• Connections: Mini-USB port, Bluetooth, Rechargeable Lithium-ion Polymer battery
• Depth: 1.9 inches
• Height: 1 inches
• Width: 10.75 inches
• Weight: about 1.5 lbs.
• Warranty: 90-day limited warranty
• Included in the box: PRINTSTIK printer, AC power adapter (100v-240v), retractable USB/mini-USB cable (about 46" long), travel case, quick-start guide, and installation CD.

Design and Build

The Printstik printer is definitely not your average printer. Weighing in at less than 2 lbs. and small enough to fit in your average notebook case, it's one of a kind, at least for now.

(view large image)

It seems solidly built, although I wouldn't go dropping it on a hardwood floor, and is two-toned, silver and black being the color choices. The dimensions I gave earlier are when the Printstik is lying flat and that's the position I will describe from.

The front of the Printstik has the PRINTSTIK label and the PlanOn logo. There is a power button and a paper feed button in the top right-hand corner. Next to the power and paper feed buttons, are the data stream, printing status and battery life indicators.

(view large image)

On the left side, there is a mini-USB port and on the top, there is where the paper comes out. There is nothing on the right side or the bottom.

The back of the Printstik has the PRINTSTIK label and the PlanOn logo again as well as access to inside the printer to load a new paper cartridge.

(view large image)

Printing Quality and Use

The Printstik comes with all the software it needs to work with a notebook or Blackberry. It took about five minutes to install the Printstik driver and after that setup was a breeze.

I had no problem pairing the Printstik with my notebook and printing was as easy as choosing the Printstik from the drop down menu in the Print menu.

I did not get to test the Printstik on a Blackberry, as no one in our office uses one and the Printstik can not pair with other smartphones at this time (we tried). PlanON does promise to have the Printstik compatible with other PDA's in the near future.

The Printstik prints on thermal paper and is very small, so it's not going to give you a glossy, bright ink finish. If you want that kind of result, you'll have to give up the dream of mobility for now.

Having said that, the Printstik does a fairly good job printing; there were no faded letters or smudges. It moves quickly too, it took a little under three minutes to print out two pages of directions and a small map. PlanOn quotes three pages in three minutes and I found that to be pretty accurate.

Bottom line, this is a good mobile printer if you need to print receipts, legal documents or airline tickets while traveling.

It took the battery about 150 minutes to charge, although PlanOn quotes the time for a full charge to be around 180 minutes. According to PlanOn, you should get 30 pages per charge, but I couldn't test that since the cartridge only comes with 20 pages.

(view large image)

Conclusion

The Printstik is a great device and can be extremely useful depending on your needs. True, you give up quality and quantity for mobility and size but for a road warrior, this could make sense.

The biggest problem I have with the Printstik is the $300 price tag. For less than what you would pay for a Printstik, you can get a normal sized printer with resolution of 4800 x 1200 dpi and can print up to 35 pages per minute (based on the specs of a HP Deskjet or HP Officejet Pro but there are multiple examples). Of course, a normal printer isn't nearly as portable as this mobile printer.

Pros:

• One-piece, easy to use unit
• Bluetooth or USB
• Rechargeable, portable
• Thermal prints are easy to read

Cons:

• Expensive
• Limited system compatibility (PC's or Blackberry)
• Paper cartridge refills expensive

Pricing and Availability

The PlanOn PRINTSTIK is priced at $299.99 and is available for purchase on the PlanOn website.

UPDATE:

I added several print sample imagesbelow. As you can see from the images, the overall print quality is decent and the text quality is good. The map,CincinnatiUSA adand the exit images are all pixilated because they were in color and a thermal printer doesn't do color. I hope this helps.

(view large image)

(view large image)

(view large image)

(view large image)



Thanks for this interesting review. The portable printer market is somewhat neglected these days. What should be mentioned is the 20 page paper cartridge costs $25. I wonder if good old thermal fax paper would work with this printer?

The PRINTSTIK is significantly more compact but not much lighter than my 2lb Canon BJC-55 (which uses normal paper). In fact, the PRINTSTIK reminds me of the Epson P-80 printer from 1985 (details here and a photo here). Arguably, the P-80 was more versatile because one could use a thermal ribbon onto normal paper (and get very good quality output compared with the dot-matrix printers common at that time).

John



What are some great alternatives for a portable printer like this one? I just googled the BJC-55 and it almost twice as expensive.



Rarity value. My BJC-55 cost about US$300 in 2002. Fortunately the XP driver manages to work with Vista.

For some reason the mainstream printer manufacturers have pulled out of this market. There used to also be a reasonably portable HP.

John



A picture of the printed products would have been nice.



Yeah second that.

Great other than that.

72oo



This review would have been much better with a picture of a print-out.



Interesting review. I didn't know they made compact printers, and here they had them in 1985! You don't really see them at the store these days though. I like this one, except for the price - $300 and expensive paper isn't enough to justify buying one over running down to the library to print stuff.



Pentax Pocketjets which have been around for some years.

http://www.pentaxtech.com/Products/pocketjets.html

They use thermal printing. Lightweight around 1.12 lbs. Pricing about $349-$449 at Portableone.com.

http://www.laptopsinc.com/Merchant2/merchant.mvc?Screen=CTGY&Store_Code=GC&Category_Code=Print



Thanks for that Pocketjet link. If I ever need one I'll have to import it. UK pricing is worse than ridiculous.

Something else regarding these thermal printers, unless someone knows better, is that they are black and while only.

John



No photo of a printout? That's like reviewing a game and having no screenshots. Unforgivable!



Hey guys - I'm going to try and have a picture of a printout up by the end of the day. I should have thought of that earlier.
