Infocus LP120 Projector Review

by Jesse A. Francis, Michigan USA

Introduction
- Product Overview

Performance
- Picture Quality
- Connectivity
- Zoom/Lens

Form Factor
- Size & Weight

Other
- Noise & Heat

Conclusion

First Glance

The first thing you'll notice about the Infocus LP120 projector is it's wonderfully small form factor. This mobile projector is very small (2.05" (H) x 3.69" (L) x 9.75" (W)) and light weight (1.98lbs). The LP120 could fit inside of a laptop carrying case, which reduces the amount of baggage required for travel. But can a projector with such small stature be able to perform to task? Read on to find out!Next >>

Specifications (from www.infocus.com)

GENERAL Native Resolution - XGA 1024 x 768 Brightness - 1000 max ANSI lumens Contrast Ratio - 2000:1 full on/full off Display Technology - DLP by Texas Instruments: 0.7" XGA 12 DMD DDR Computer Compatibility - SXGA, XGA, SVGA, VGA, Macintosh Video Compatibility: Full NTSC, PAL, SECAM Digital Keystone Correction: 7.5 vertical correction Aspect Ratio - 4:3 SIZE Dimensions - 2.05" (H) x 3.69" (L) x 9.75" (W) - 5.21 cm (H) x 9.37 cm (L) x 24.77 cm (W) Weight - 1.98 lbs/0.9 kg INPUT Computer (M1-DA) Video (S-Video; RCA via standard S-Video to RCA input adapter) Audio (3.5 mm mini jack) OTHER Number of Colors - 16.7 million H-Synch Range - 15 - 100 kHz V-Synch Range - 43.5 - 130 Hz Pixel Clock - Digital 112 MHz (max); analog 135 MHz (max) Image Offset - 112% Projection Lens - Zoom lens with manual focus and manual zoom adjust Throw Ratio - 1.8 - 2.1:1 (typical) Minimum Projection Distance - 1.5 m (maximum distance 5.0 m) Image Size (diagonal) - 2.9' to greater than 11.5'/0.9 m to greater than 3.5 m Projection Methods - Front and rear Audio - 1-watt speaker Control - Projector keypad; IR remote control; wired control through USB Lamp - 120W UHP / 2000 (typical) Power Consumption - 150 watts Power Supply - 100V - 240V at 50 - 60 Hz Operating Temperature - 5 - 40 C at sea level (0' - 10,000'), 41 - 104 F Menu Languages - English, Norwegian, Spanish, Italian, Portuguese, German, French, Chinese (simplified), Chinese (traditional), Japanese, Russian, Korean Audible Noise - 37dB Approvals - FCC A (US/Canada), S-JQA (Japan), PSE (Japan), CCC (China), IRAM (Argentina), GOST (Russia), UL & cUL (US/Canada), TUV GS (Germany), NOM (Mexico), MIC (Korea), C-Tick (Australia) Lamp Warranty - 90 days or 500 hours, whichever comes first Product Warranty - 2 years: parts and labor Accessory Warranty - 1 year
