    How are the SATA ports arranged?

    Discussion in 'MSI' started by Synomenon, Aug 30, 2015.

  1. Synomenon

    Synomenon Notebook Guru

    Reputations:
    0
    Messages:
    62
    Likes Received:
    5
    Trophy Points:
    16
    Ok, so I have a:
    GT72 2QD-1445US
    Product SKU: BB7570H16G1T0S81M
    Model: 9S7-178131-1445

    I know there are two SATA ports (optical drive and one 2.5" drive bay) and another four routed to the m.2 "sled".

    Is it true that the optical drive and 2.5" drive bay ports are SATA 2 only? I have a Samsung 850 Pro. and if that's the case, I'll have to find a m.2 to SATA adapter so I can use that 850 Pro. in the open 2.5" drive bay.

    Synomenon, Aug 30, 2015
    #1
  2. Meaker@Sager

    Meaker@Sager Company Representative

    Reputations:
    9,436
    Messages:
    58,194
    Likes Received:
    17,902
    Trophy Points:
    931
    All SATA III ports the chipset can provide (4 max) go to the m.2 slots so yes you are correct.

    Meaker@Sager, Aug 31, 2015
    #2
  3. Synomenon

    Synomenon Notebook Guru

    Reputations:
    0
    Messages:
    62
    Likes Received:
    5
    Trophy Points:
    16
    Synomenon, Aug 31, 2015
    #3
  4. Meaker@Sager

    Meaker@Sager Company Representative

    Reputations:
    9,436
    Messages:
    58,194
    Likes Received:
    17,902
    Trophy Points:
    931
    Someone already did do a similar thing and got it working. So long as you can physically fit it then it will work electrically.

    Meaker@Sager, Aug 31, 2015
